AZ-400 Practice Questions

1. Sign in to the portal,

2. Choose template Deploy-lod9940427

3. Select Edit template, andthen paste your JSON template code into the code window.

4. Change the ASddressPrefixes to 10.0.0.0/24 in order to support only 256 total IP addresses.

addressSpace":{"addressPrefixes": ["10.0.0.0/24"]},

5. Change the firstSubnet addressprefix to 10.0.0.0/26 to support only 64 total IP addresses.

"subnets":[

{

"name":"firstSubnet",

"properties":{

"addressPrefix":"10.0.0.0/24"

}

6. Select Save.

7. Select Editparameters, provide values for the parameters that are shown, and then select OK.

8 Select Subscription. Choose the subscription you want to use, and then select OK.

9. Select Resource group. Choose an existing resource group or create a new one, and then select OK.

10. Select Create. A new tile on the dashboard tracks the progress of your template deployment.

You can usea system-assigned managed identity for a Windows virtual machine (VM) to access Azure Key Vault.

Sign in to Azure portal

Locate virtual machine VM1.

Select Identity

Enable the system-assigned identity for VM1 by setting the Status to On.

Note:Enabling a system-assigned managed identity is a one-click experience. You can either enable it during the creation of a VM or in the properties of an existing VM.

Task 8: Create a Service Hook to Integrate with Azure Storage (queue1)

Step 1: Verify the Storage Account and Queue

In the Azure portal (https://portal.azure.com ):

Go to Storage accounts.

Find the storage48901628 storage account.

In the left menu, click on Queues.

Ensure that a queue named queue1 exists.If not, create it by:

Clicking + Queue.

Enter Name: queue1.

Click OK.

Step 2: Prepare the Storage Account’s Shared Access Signature (SAS)

Azure DevOps uses SAS tokens to send messages to a storage queue.

In the Azure portal, go to the storage48901628 storage account.

In the left menu, click Shared access signature.

Set the following:

Allowed services: Queue.

Allowed resource types: Object.

Allowed permissions: Add, Write.

Start and expiry date/time: Adjust as needed (e.g., 1 year).

Click Generate SAS and connection string.

Copy the Queue SAS URL (e.g., https://storage48901628.queue.core.windows.net/queue1?sv=...).

Step 3: Create the Service Hook in Azure DevOps

In your Azure DevOps Project (Project1):

In the bottom-left, click Project settings.

In the left menu, click Service hooks.

Click + Create subscription.

Step 4: Configure the Azure Storage Service Hook

In the Create a subscription wizard, choose Azure Storage Queues and click Next.

Choose the Trigger:

For example: Code pushed (or other events you want to send to the queue).

Click Next.

Configure the Action:

Queue endpoint URL: The Queue SAS URL you copied in Step 2 (including the queue1 endpoint and SAS token).

Example:

bash

Copy

https://storage48901628.queue.core.windows.net/queue1?sv=...

Step 5: Finalize and Test the Integration

Click Test to ensure Azure DevOps can send a message to the queue.

If the test succeeds, click Finish to create the service hook.

Step 6: Validate in the Azure Portal

In the Azure portal, go to storage48901628 > Queues > queue1.

You should see new messages appear in the queue whenever the configured Azure DevOps event (like push or PR) occurs.

1. Open Microsoft Azure Portal

2. Select All Services, and then select DevTest Labs in the DEVOPS section.

3. From the list of labs, select the az400-9940427-dtl1 lab

4. On the home page for your lab, select + Add on the toolbar.

5. Select the Windows Server 2016 Datacenter base image for the VM.

6. Select automation options at the bottom of the page above the Submit button.

7. You see the Azure Resource Manager template for creating thevirtual machine.

8. The JSON segment in the resources section has the definition for the image type you selected earlier.

Step 1: To create a general-purpose v2 storage account in the Azure portal, follow these steps:

On the Azure portal menu, select All services. In the list of resources, type Storage Accounts. As you begin typing, the list filters based on your input. Select Storage Accounts.

On the Storage Accounts window that appears, choose Add.

Select the subscription in which to create thestorage account.

Under the Resource group field, select RG1lod11566895

Next, enter a name for your storage account named: az400lod11566895stor

Select Create.

Step 2: Enable boot diagnostics on existing virtual machine

To enable Boot diagnostics on an existing virtual machine, follow these steps:

Sign in to the Azure portal, and then select the virtual machine VM1.

In the Support + troubleshooting section, select Boot diagnostics, then select the Settings tab.

In Boot diagnostics settings, change the statusto On, and from the Storage account drop-down list, select the storage account az400lod11566895stor.

Save the change.

You must restart the virtual machine for the change to take effect.

1. To enable automatictuning on a single database, navigate to the database in the Azure portal and select Automatic tuning.

2. Select the automatic tuning options you want to enable and select Apply.

Note: Individual automatic tuning settings can be separately configuredfor each database. You can manually configure an individual automatic tuning option, or specify that an option inherits its settings from the server.

Step 1: Navigate to Personal Access Tokens

Sign in to Azure DevOps:

Go to Azure DevOps and sign in with your credentials.

Access User Settings:

Click on your profile picture in the top right corner.

Select User settings.

Open Personal Access Tokens:

In the user settings menu, select Personalaccess tokens.

Step 2: Create a New Personal Access Token

Create a New Token:

Click on + New Token.

Configure the Token:

Name: Enter Token1.

Organization: Select the organization where you want to use the token.

Expiration: Set the expiration to 60 days.

Set Scopes:

Code: Select Read, Write, & Manage.

Build: Select Read & Execute.

Release: Select Read.

Create the Token:

Click on Create.

Step 3: Save the Token

Copy the Token:

Once the token is created, copy it immediately as it will not be displayed again.

Store the token in a secure location.

By following these steps, you will have successfully created a personal access token named Token1 with the specified capabilities and a 60-day expiration

1. Open Microsoft Azure Portal, and select the Azure Container Registry instance named az4009940427acr1.

2. Under Policies, select Content Trust > Enabled > Save.

To create an instance of Azure Application Insights namedaz400-38443478-mainand configure it to receive telemetry data from an Azure web app with the same name, you’ll need to follow these steps:

Create a Log Analytics Workspace:

Go to theAzure Portal.

Search for Log Analytics Workspaces and select Add.

Select a Subscription and either use an existing Resource Group or create a new one.

Provide a unique name for your Log Analytics workspace.

Choose the Region that is appropriate for you.

Review the settings and then selectCreate1.

Create an Azure Application Insights Instance:

In the Azure Portal, navigate to Application Insights.

Click on + Create.

Fill in the instance details, ensuring the name isaz400-38443478-main.

Link the instance to the Log Analytics workspace you created in the previous step.

Review and create the Application Insights instance2.

Configure the Azure Web App to Send Telemetry Data:

Go to the Azure Web Appaz400-38443478-main.

Under Monitoring, selectApplication Insights.

Choose to use an existing resource and select the Application Insights instance you created.

Follow the prompts to set up the connection, which may involve adding the appropriate SDK to your web app and configuring the connection string or instrumentation key.

Verify Telemetry Data Reception:

After setting up, send some test traffic to your web app.

Then, go to the Application Insights instance and check the Overview or Performance sections to see if telemetry data is being received.

Remember to replace placeholder names with the actual names of your resources where necessary. These steps will help you set up Azure Application Insights to monitor your web app effectively.

Task 9: Initialize the main branch (if it doesn’t exist) and create a pull request-triggered pipeline for .NET Core build

Step 1: Initialize the main Branch

In your Azure DevOps Project (Project1), navigate to Repos.

In the left menu, click Files.

If you see a message like “This repository is empty,” click Initialize.

Create a READM

E.

md file (or another file) and set the default branch name to main.

Click Initialize.

If the main branch already exists, you can skip this step.

Step 2: Create a New Branch for the Pipeline

In Repos > Files, click on the Branches tab.

Click New branch.

Enter:

Branch name: azure-pipelinesT

Based on: main

Click Create.

This creates a new branch named azure-pipelinesT from main.

Step 3: Create the Pipeline YAML File in the New Branch

Switch to the azure-pipelinesT branch.

In Files, click New file.

Name the file: azure-pipelines.yml.

Step 4: Write the YAML Pipeline for .NET Core Build

Here’s a sample YAML file:

trigger: none

pr:

branches:

include:

- main

pool:

vmImage: 'windows-latest'

variables:

buildConfiguration: 'Release'

steps:

- task: UseDotNet@2

displayName: 'Install .NET Core SDK'

inputs:

packageType: 'sdk'

version: '8.x' # Or specify the exact version of .NET Core SDK you need

installationPath: $(Agent.ToolsDirectory)/dotnet

- script: dotnet build src --configuration $(buildConfiguration)

displayName: 'Build .NET Core project'

This pipeline:

Runs only when a pull request is created or updated targeting the main branch.

Uses the windows-latest agent.

Installs the .NET SDK and builds the project in the src directory.

Step 5: Commit the Pipeline File

In the bottom commit message box:

Message: Add PR-triggered pipeline for .NET Core build

Ensure the branch is set to azure-pipelinesT.

Click Commit.

Step 6: Create the Pipeline in Azure DevOps

In the left menu, click Pipelines.

Click New pipeline.

Select:

Azure Repos Git.

Select your repository.

Choose Existing Azure Pipelines YAML file.

In the branch selector, choose the azure-pipelinesT branch.

Select the YAML file path (azure-pipelines.yml).

Click Continue and Run to validate.

Step 7: Test the Pipeline Trigger

Create a new branch (e.g., feature/test-pr).

Push a commit and create a pull request targeting main.

Verify that the pipeline runs automatically for this PR in Pipelines.
