F5CAB1 Practice Questions

Self-IPs include a security feature called Port Lockdown , which restricts which services respond on that Self-IP.

By default, Self-IPs block management access (SSH and HTTPS/TMUI), meaning an administrator cannot manage the device through in-band Self-IPs unless explicitly allowed.

Allow Mgmt / Allow Management

These settings enable only the management services required for administrative access, specifically:

SSH (22)

HTTPS/TMUI (443)

These options allow secure administration without opening unnecessary ports.

Why these are correct:

They provide only the essential access for management.

They follow F5 security best practices when using in-band admin access.

They do not expose all services, reducing the attack surface.

Why the other options are incorrect:

A.

This allows only a minimal set of system-required ports (e.g., failover, config sync), not SSH or HTTPS.

Administrator access would still fail.

B.

Opens all ports on the Self-IP, which is not secure .

Exposes services that should remain restricted.

Therefore, Allow Mgmt / Allow Management are the correct choices.

Comprehensive and Detailed Explanation From BIG-IP Administration — Install, Initial Configuration, and Upgrade:

When provisioning modules on a BIG-IP system, F5 provides specific resource allocation settings that define how system resources — CPU, memory, and disk — are distributed to each licensed module. The two valid and officially recognised allocation settings are Nominal and Dedicated .

Nominal instructs the system to allocate a moderate, balanced share of resources to the module. It allows the module to function effectively while sharing system resources with other provisioned modules. This is the most commonly used setting in multi-module deployments.

Dedicated allocates the maximum available system resources exclusively to a single module. When this setting is applied, it is typically the only module provisioned, as it consumes resources at a level that prevents other modules from operating concurrently in a meaningful capacity.

Option A — Maximum is not a valid BIG-IP provisioning allocation level; it does not appear in the official provisioning interface or documentation as a selectable resource tier.

Option C — Limited similarly does not exist as a defined resource allocation setting within BIG-IP module provisioning. It may superficially resemble valid terminology but has no standing in the official provisioning framework.

Administrators access these settings via System » Resource Provisioning in the Configuration Utility, where each licensed module displays its available allocation options.

Reference Topics: Module Resource Provisioning, Nominal vs. Dedicated Allocation, System Resource Management — BIG-IP Administration Study Guide.
