Free Administering Relational Databases on Microsoft Azure Practice Questions

To ensure that any enhancements made to the Query Optimizer through patches are available to dbl and db2 on sql37006895, you need to enable the query optimizer hotfixes option for each database. This option allows you to use the latest query optimization improvements that are not enabled by default1. You can enable this option by using the ALTER DATABASE SCOPED CONFIGURATION statement2.

Here are the steps to enable the query optimizer hotfixes option for dbl and db2 on sql37006895:

Connect to sql37006895 using SQL Server Management Studio, Azure Data Studio, or any other tool that supports Transact-SQL statements.

Open a new query window and run the following commands for each database:

-- Switch to the database context

USE dbl;

GO

-- Enable the query optimizer hotfixes option

ALTER DATABASE SCOPED CONFIGURATION SET QUERY_OPTIMIZER_HOTFIXES = ON;

GO

Repeat the same commands for db2, replacing dbl with db2 in the USE statement.

To verify that the query optimizer hotfixes option is enabled for each database, you can query the sys.database_scoped_configurations catalog view. The value of the query_optimizer_hotfixes column should be 1 for both databases.

These are the steps to enable the query optimizer hotfixes option for dbl and db2 on sql37006895.

To configure sq1370O6895 to support the creation of new database users from Azure AD identities, you need to do the following steps:

Set up a Microsoft Entra tenant and associate it with your Azure subscription. You can use the Microsoft Entra portal or the Azure portal to create and manage your Microsoft Entra users and groups12.

Configure a Microsoft Entra admin for sq1370O6895.  You can use the Azure portal or the Azure CLI to set a Microsoft Entra user as the admin for the server34. The Microsoft Entra admin can create other database users from Microsoft Entra identities5.

Connect to db1 using the Microsoft Entra admin account and run the following Transact-SQL statement to create a new database user from a Microsoft Entra identity: CREATE USER [Microsoft Entra user name] FROM EXTERNAL PROVIDER;6 You can replace the Microsoft Entra user name with the name of the user or group that you want to create in the database.

Grant the appropriate permissions to the new database user by adding them to a database role or granting them specific privileges. For example, you can run the following Transact-SQL statement to add the new user to the db_datareader role: ALTER ROLE db_datareader ADD MEMBER [Microsoft Entra user name];

These are the steps to configure sq1370O6895 to support the creation of new database users from Azure AD identities.

Apply an Azure Resource Manager Delete lock / CanNotDelete lock directly to the Azure SQL database resource db1.

Microsoft states that Azure resource locks can be applied at subscription, resource group, or resource scope to protect resources from accidental deletion or modification. In the Azure portal, the lock types are shown as Delete and Read-only; in CLI/PowerShell, they are called CanNotDelete and ReadOnly. A CanNotDelete/Delete lock allows users to read and modify the resource, but prevents deletion.

Azure Portal Method — Recommended for Simulation

Step 1: Open the database resource

Sign in to the Azure portal.

In the search bar, search for SQL databases.

Select the database named db1.

Make sure you select the database resource itself, not only the SQL logical server.

Step 2: Open Locks

In the left menu of db1, scroll to Settings.

Select Locks.

Select Add.

Step 3: Create the delete lock

Configure the lock as follows:

Setting

Value

Lock name

PreventDelete-db1

Lock type

Delete

Notes

Prevent accidental deletion of db1

Then select OK or Save.

In the portal, choose Delete, not Read-only. A Read-only lock is too restrictive because it can block management updates. For this task, the requirement is only to stop accidental deletion, so Delete / CanNotDelete is the correct lock type. Microsoft confirms that CanNotDelete prevents deletion but still permits reading and modifying the resource.

Step 4: Verify the lock

Stay on the db1 database page.

Go back to Locks.

Confirm the lock exists with:

Name: PreventDelete-db1

Lock type: Delete

The task is complete once db1 has a Delete lock applied.

PowerShell Method

Use this if the lab provides Azure PowerShell.

New-AzResourceLock `

-LockLevel CanNotDelete `

-LockName " PreventDelete-db1 " `

-LockNotes " Prevent accidental deletion of db1 " `

-ResourceGroupName " < resource-group-name > " `

-ResourceName " < sql-server-name > /db1 " `

-ResourceType " Microsoft.Sql/servers/databases "

Microsoft’s New-AzResourceLock documentation includes an Azure SQL Database example using resource type Microsoft.Sql/servers/databases and resource name format serverName/databaseName.

Example format:

New-AzResourceLock `

-LockLevel CanNotDelete `

-LockName " PreventDelete-db1 " `

-LockNotes " Prevent accidental deletion of db1 " `

-ResourceGroupName " RG1 " `

-ResourceName " sql60152867/db1 " `

-ResourceType " Microsoft.Sql/servers/databases "

Replace RG1 and sql60152867 with the actual resource group and SQL logical server that hosts db1.

Azure CLI Method

Use Azure CLI only if the lab gives Cloud Shell and you know the full resource I

D.

First get the database resource ID:

az sql db show \

--resource-group < resource-group-name > \

--server < sql-server-name > \

--name db1 \

--query id \

--output tsv

Then create the lock:

az resource lock create \

--name PreventDelete-db1 \

--lock-type CanNotDelete \

--resource < database-resource-id > \

--notes " Prevent accidental deletion of db1 "

Azure CLI supports resource-level lock creation with --lock-type CanNotDelete or ReadOnly.

SSMS / T-SQL Clarification

SSMS is not the correct tool for this task.

A delete lock is an Azure Resource Manager control-plane setting, not a SQL data-plane setting. SQL Server Management Studio can manage database objects and run T-SQL, but it cannot create Azure portal deletion protection locks for an Azure SQL Database.

Requirement: Configure differential backups for Azure SQL Database db1 to run once a day instead of twice a day.

Correct setting: Change Differential backup frequency from 12 Hours to 24 Hours.

Azure SQL Database supports differential backup frequency of either 12 hours or 24 hours. A 12-hour frequency means twice per day; a 24-hour frequency means once per day. Microsoft also notes that 24-hour differential backup frequency can increase restore time compared with 12-hour frequency.

Method 1 — Azure Portal Method

This is the best method for the simulation.

Step 1: Open the Azure SQL logical server

Sign in to the Azure portal.

Search for SQL servers.

Open the logical SQL server that hosts database db1.

Do not start from SQL Server Management Studio for this task. The differential backup frequency is an Azure SQL backup policy setting, not a normal T-SQL database setting.

Step 2: Open the Backups page

In the SQL server left menu, select Backups.

Select the Retention policies tab.

Microsoft’s documented portal path is to go to the logical SQL server, select Backups, then select the Retention policies tab.

Step 3: Select database db1

In the list of databases, locate db1.

Select the checkbox next to db1.

Select Configure policies from the action bar.

Step 4: Change the differential backup frequency

In the policy configuration pane:

Find Differential backup frequency.

Change it from:

12 Hours

to:

24 Hours

Leave the PITR retention period unchanged unless the task specifically tells you to change it.

Select Apply or Save.

Microsoft’s documented option is exactly 12 Hours or 24 hours under Differential backup frequency.

Method 2 — Azure CLI Method

Use this if the simulation provides Cloud Shell.

az sql db str-policy set \

--resource-group < resource-group-name > \

--server < server-name > \

--name db1 \

--retention-days < current-retention-days > \

--diffbackup-hours 24

Example:

az sql db str-policy set \

--resource-group RG1 \

--server sql60152867 \

--name db1 \

--retention-days 7 \

--diffbackup-hours 24

Microsoft documents az sql db str-policy set with --diffbackup-hours 24 for changing active database differential backup frequency. Valid values are 12 or 24 hours.

Be careful: do not guess the retention days blindly in a real environment. In the exam lab, use the existing retention value shown in the portal unless the task also asks you to change retention.

Method 3 — PowerShell Method

Use this if Azure PowerShell is available.

Set-AzSqlDatabaseBackupShortTermRetentionPolicy `

-ResourceGroupName " < resource-group-name > " `

-ServerName " < server-name > " `

-DatabaseName " db1 " `

-RetentionDays < current-retention-days > `

-DiffBackupIntervalInHours 24

Microsoft documents Set-AzSqlDatabaseBackupShortTermRetentionPolicy with -DiffBackupIntervalInHours 24 for setting Azure SQL Database differential backup frequency.

SSMS / T-SQL Clarification

For this task, SSMS is not the right tool to change the setting.

There is no normal ALTER DATABASE T-SQL command in Azure SQL Database to change automated differential backup frequency. Microsoft documents this change through:

Azure portal

Azure CLI

PowerShell

REST API

not SSMS/T-SQL.

You may use SSMS only to confirm the database exists and is accessible, but the backup frequency setting must be changed from Azure management tools.

To generate an email alert to admin@contoso.com when CPU percentage utilization for db1 is higher than average, you can use the Azure portal to create an alert rule based on the CPU percentage metric. Here are the steps to do that:

Go to the Azure portal and select your Azure SQL Database server that hosts db1.

Select Alerts in the Monitoring section and click on New alert rule.

In the Condition section, click Add and select the CPU percentage metric.

In the Configure signal logic page, set the threshold type to Dynamic. This will compare the current metric value to the historical average and trigger the alert when it deviates significantly1.

Set the operator to Greater than, the aggregation type to Average, the aggregation granularity to 1 minute, and the frequency of evaluation to 5 minutes.

Click Done to save the condition.

In the Action group section, click Create and enter a name and a short name for the action group.

In the Notifications section, click Add and select Email/SMS message/Push/Voice.

Enter admin@contoso.com in the Email field and click OK.

Click OK to save the action group.

In the Alert rule details section, enter a name and a description for the alert rule, choose a severity level, and make sure the rule is enabled.

Click Create alert rule to create the alert rule.

This alert rule will send an email to admin@contoso.com when the CPU percentage utilization for db1 is higher than average. You can also add other actions to the alert rule, such as calling a webhook or running an automation script

Enable Automatic tuning at the server level and turn Create Index to On.

Microsoft states that Azure SQL Database automatic tuning can create indexes automatically, verify performance improvement, and roll back changes if performance regresses. Server-level automatic tuning settings are applied to all databases on the server by default, unless a database has its own override.

Azure Portal Method — Recommended for Simulation

Step 1: Open the SQL logical server

Sign in to the Azure portal.

Search for SQL servers.

Open:

sql60152867

Do not open only db1. The task says all databases on sql60152867, so configure this at the server level.

Step 2: Open Automatic tuning

In the SQL server left menu:

Go to Intelligent Performance.

Select Automatic tuning.

Microsoft’s documented path is to open the Azure SQL server in the portal and select Automatic tuning from the menu.

Step 3: Enable automatic index creation

On the Automatic tuning page, configure:

Setting

Value

Create index

On

Drop index

Leave unchanged unless required

Force last good plan

Leave unchanged unless required

The only required setting is:

Create index = On

Do not confuse this with Drop index. The task only asks to ensure indexes are created automatically.

Step 4: Apply the setting

Select Apply or Save.

Wait for the portal confirmation.

The setting is now configured at the SQL logical server level.

Important Database Inheritance Check

This is the part people miss.

Server-level automatic tuning applies to databases that inherit from the server. Microsoft states that individual databases can override server-level automatic tuning settings. Therefore, if the simulation shows any database with custom automatic tuning settings, set that database to Inherit from server or manually set Create index = On for that database.

For each database, the correct inherited state should be:

Automatic tuning = Inherit from server

Create index = Inherited / On

If a database is set to:

Custom

Create index = Off

then the server-level setting might not affect that database. Fix it.

Database-Level T-SQL Method

Use this only if the portal is unavailable or you need to correct a specific database override.

Connect to each database and run:

ALTER DATABASE CURRENT

SET AUTOMATIC_TUNING (

CREATE_INDEX = ON

);

Microsoft documents this exact syntax for enabling the CREATE_INDEX automatic tuning option by T-SQL on an individual Azure SQL Database.

To make an individual database inherit server settings, run:

ALTER DATABASE CURRENT

SET AUTOMATIC_TUNING = INHERIT;

But this must be executed inside each database, not from master as a single server-wide T-SQL command.

Verification with T-SQL

Connect to a database and run:

SELECT

name,

desired_state_desc,

actual_state_desc

FROM sys.database_automatic_tuning_options

WHERE name = ' CREATE_INDEX ' ;

Expected result:

name CREATE_INDEX

desired_state_desc ON or DEFAULT

actual_state_desc ON

If desired_state_desc is DEFAULT, that usually means the database is inheriting the server-level setting. The key result is:

actual_state_desc = ON

SSMS Clarification

SSMS can be used to verify or configure the setting per database using T-SQL, but it is not the best tool for the requirement as written.

Because the task says:

all the databases on sql60152867

the correct primary method is:

Azure portal > SQL server > Automatic tuning > Create index = On

Final Exam-Lab Action

Configure this:

SQL server: sql60152867

Automatic tuning

Create index: On

Apply

Then verify databases are inheriting the server setting or have CREATE_INDEX = ON.

That completes the task.

Requirement: Configure active geo-replication for Azure SQL Database db1. The geo-replica must be created in East US or East US 2 on the logical Azure SQL server:

sql60152867-dr.database.windows.net

The important point: in Azure SQL, the logical server name used in portal/T-SQL is usually:

sql60152867-dr

not the full FQDN.

Microsoft states that active geo-replication is configured per database, and a geo-secondary is created for an existing Azure SQL Database. After creation and seeding, changes from the primary are replicated asynchronously to the secondary.

Method 1 — Azure Portal Method

This is the safest method for the simulation if the portal is available.

Step 1: Open the primary database

Sign in to the Azure portal.

Search for SQL databases.

Select the database named db1.

Confirm you are looking at the primary database, not an existing secondary.

Step 2: Open the Replicas blade

In the left menu of the db1 database page, scroll to Data management.

Select Replicas.

Select Create replica.

Microsoft’s portal workflow is: open the database, go to Data management > Replicas, and choose Create replica.

Step 3: Configure the geo-secondary replica

On the Create SQL Database replica page, configure the target like this:

Setting

Value

Database

db1

Replica type

Geo replica / Active geo-replication

Target server

sql60152867-dr

Region

East US or East US 2

Database name

db1

Compute + storage

Keep same or compatible with primary

Elastic pool

Only choose this if the lab specifically requires an elastic pool

Do not create a failover group unless the task asks for one. This task says active geo replication, so configure a database-level geo-replica, not a failover group. Microsoft explicitly separates active geo-replication from failover groups and notes that active geo-replication is configured per database.

Step 4: Review and create

Select Review + create.

Confirm the target server is:

sql60152867-dr

Confirm the region is either:

East US

or

East US 2

Select Create.

Azure will create the secondary database and begin the seeding process. Microsoft notes that the secondary database has the same name as the primary by default and begins replication after it is created and seeded.

Step 5: Verify replication

After deployment completes:

Go back to the primary database db1.

Open Replicas again.

Under Geo replicas, confirm that a replica exists on:

sql60152867-dr.database.windows.net

Confirm the replica status is healthy, online, or synchronizing.

You can also open the target SQL server sql60152867-dr and verify that a database named db1 now exists there.

Method 2 — SSMS / T-SQL Method

Use this method if the portal is awkward or the exam simulation expects T-SQL.

Step 1: Allow SSMS connectivity

Before connecting with SSMS:

In Azure portal, open the primary SQL server hosting db1.

Go to Networking or Firewalls and virtual networks.

Add your client IP address.

Repeat this on the secondary server:

sql60152867-dr.database.windows.net

This matters because SSMS must be able to connect to the Azure SQL logical server.

Step 2: Connect to the primary server in SSMS

Open SQL Server Management Studio.

Connect to the primary Azure SQL logical server that hosts db1.

Use SQL admin credentials or Microsoft Entra admin credentials.

In Connection Properties, connect to the database:

master

This is important. For Azure SQL Database geo-replication setup through T-SQL, run the command from the master database on the primary server.

Step 3: Run the active geo-replication command

Run this query:

ALTER DATABASE [db1]

ADD SECONDARY ON SERVER [sql60152867-dr]

WITH (ALLOW_CONNECTIONS = ALL);

Microsoft documents that ALTER DATABASE ... ADD SECONDARY ON SERVER creates a secondary database for an existing Azure SQL Database and starts data replication. The official example also uses WITH (ALLOW_CONNECTIONS = ALL) to create a readable geo-secondary.

Step 4: Verify the replication link

Still connected to the primary server, run:

SELECT *

FROM sys.geo_replication_links;

Or use:

SELECT *

FROM sys.dm_geo_replication_link_status;

Microsoft lists sys.geo_replication_links and sys.dm_geo_replication_link_status as views used to return information about existing replication links and replication status.

Optional PowerShell Method

Only use this if the lab gives you Cloud Shell or PowerShell access.

New-AzSqlDatabaseSecondary `

-ResourceGroupName " < PrimaryResourceGroupName > " `

-ServerName " < PrimaryServerName > " `

-DatabaseName " db1 " `

-PartnerResourceGroupName " < SecondaryResourceGroupName > " `

-PartnerServerName " sql60152867-dr " `

-PartnerDatabaseName " db1 "

Microsoft identifies New-AzSqlDatabaseSecondary as the PowerShell cmdlet that creates a secondary database for an existing Azure SQL Database and starts replication.

Final Answer / What You Must Achieve

The task is complete when:

Database db1 still exists on the primary server.

A secondary database named db1 exists on:

sql60152867-dr.database.windows.net

The target server is in East US or East US 2.

The replica appears under db1 > Replicas > Geo replicas.

Replication status is healthy, online, seeding, or synchronizing.

You did not configure a failover group unless separately requested.

Use SQL Server Management Studio Always Encrypted Wizard and encrypt:

Database: db1

Schema: SalesLT

Table: Customer

Column: LastName

Encryption feature: Always Encrypted

Column master key store: Windows Certificate Store

Do not use Transparent Data Encryption. TDE encrypts the database at rest, but this task specifically requires Always Encrypted, which protects selected columns and keeps the encryption keys outside the database engine. Microsoft states that Always Encrypted uses column encryption keys to encrypt column data and column master keys to protect those column encryption keys. Column master keys are stored outside the database system, such as in the Windows certificate store.

Method 1 — SSMS Always Encrypted Wizard

This is the correct method for the simulation.

Step 1: Open SSMS and connect to Azure SQL Database

Open SQL Server Management Studio.

Connect to the Azure SQL logical server that hosts db1.

Use a SQL admin account or Microsoft Entra admin account.

In Options > Connection Properties, select database:

db1

Connect.

If SSMS cannot connect, go to the Azure portal and add your client IP address under the SQL server firewall/networking settings.

Step 2: Open the table column

In Object Explorer:

Expand Databases.

Expand db1.

Expand Tables.

Expand:

SalesLT.Customer

Expand Columns.

Locate:

LastName

Microsoft confirms that the Always Encrypted Wizard can be launched at the database, table, or individual column level. For one column, the cleanest path is to launch it directly from the column.

Step 3: Launch the Always Encrypted Wizard

Right-click the LastName column, then select:

Encrypt Column

or, depending on the SSMS version:

Always Encrypted Wizard

Alternative path:

Right-click db1 > Tasks > Always Encrypted Wizard

Then manually select:

SalesLT.Customer.LastName

Step 4: Select the LastName column for encryption

On the Column Selection page:

Find:

SalesLT.Customer.LastName

Select the checkbox for LastName.

Set the encryption type.

Use:

Randomized

unless the lab specifically requires searching or equality filtering on LastName.

Reason: Randomized encryption is stronger because identical plaintext values produce different ciphertext values. Deterministic encryption allows equality lookups, joins, grouping, and indexing, but leaks more pattern information because identical plaintext values produce identical encrypted values. Microsoft describes deterministic encryption as query-friendly but more pattern-revealing, while randomized encryption is more secure but does not support normal searching/grouping/joining without secure enclaves.

For this task, the requirement is only to encrypt the LastName column, so Randomized is the safer default.

Step 5: Choose or create a Column Encryption Key

For Encryption Key, select a new key such as:

CEK_Auto1

or create a new column encryption key if one does not already exist.

This is the key that encrypts the data in the LastName column. Microsoft states that a column encryption key encrypts the data in encrypted columns, and the column master key encrypts/protects the column encryption key.

Select Next.

Step 6: Configure the Column Master Key in Windows Certificate Store

On the key configuration page, create a new Column Master Key.

Use settings like:

Setting

Value

Column master key name

CMK_WindowsCert or default generated name

Key store

Windows Certificate Store

Certificate location

Current User

Certificate

Generate new certificate

Column encryption key

CEK_Auto1 or default generated CEK

In many SSMS versions, the wizard creates both:

CMK_Auto1

CEK_Auto1

That is acceptable as long as the CMK key store is Windows Certificate Store.

Microsoft states that SQL Server Management Studio supports column master keys stored in the Windows Certificate Store, and that a column master key can be a certificate stored in Windows Certificate Store.

Step 7: Run the wizard

On the final wizard pages:

Review the configuration.

Choose:

Proceed to finish now

or:

Run immediately

Select Finish.

SSMS will generate the column master key metadata, column encryption key metadata, and perform the data encryption operation. Microsoft explains that the wizard can encrypt selected columns and can generate a new column master key and column encryption key when needed.

During encryption, SSMS may temporarily create a new table, copy data, encrypt the selected column, and swap the table back, depending on whether secure enclaves are used. Microsoft notes that the wizard can move data out of the database and perform cryptographic operations inside the SSMS process when secure enclave in-place encryption is not used.

Verification Steps

Step 1: Confirm Always Encrypted metadata exists

Run this in db1:

SELECT

name,

key_store_provider_name,

key_path

FROM sys.column_master_keys;

You should see a column master key that uses the Windows certificate store provider.

Then run:

SELECT

name

FROM sys.column_encryption_keys;

You should see the column encryption key created by the wizard.

Step 2: Confirm LastName is encrypted

Run:

SELECT

t.name AS table_name,

c.name AS column_name,

c.encryption_type_desc,

cek.name AS column_encryption_key

FROM sys.columns AS c

JOIN sys.tables AS t

ON c.object_id = t.object_id

LEFT JOIN sys.column_encryption_keys AS cek

ON c.column_encryption_key_id = cek.column_encryption_key_id

WHERE t.name = ' Customer '

AND SCHEMA_NAME(t.schema_id) = ' SalesLT '

AND c.name = ' LastName ' ;

Expected result:

table_name: Customer

column_name: LastName

encryption_type_desc: RANDOMIZED

column_encryption_key: CEK_Auto1 or similar

If you selected deterministic encryption, the expected value will be:

DETERMINISTIC

The key requirement is that encryption_type_desc is no longer NULL.

Step 3: Test viewing the encrypted column

Open a new SSMS query connection without Always Encrypted enabled and run:

SELECT TOP 10 LastName

FROM SalesLT.Customer;

You should not see normal plaintext values.

Then reconnect with Always Encrypted enabled:

In SSMS, select Connect > Database Engine.

Select Options.

Go to Additional Connection Parameters.

Add:

Column Encryption Setting=Enabled

Connect again.

Run:

SELECT TOP 10 LastName

FROM SalesLT.Customer;

A client that has access to the Windows certificate/private key should be able to decrypt the values. Microsoft explains that the database stores encrypted data and key metadata, while client-side components with access to the column master key perform encryption and decryption.

Important Exam Notes

Do not choose Azure Key Vault

The task explicitly says:

You must use the Windows Certificate Store.

So the column master key should not be stored in Azure Key Vault.

Wrong:

Azure Key Vault

Correct:

Windows Certificate Store

Do not use TDE

TDE is not column-level Always Encrypted. It encrypts database files/logs at rest, but users and administrators querying the database still see plaintext if they have SQL permissions.

Correct technology:

Always Encrypted

Correct key store:

Windows Certificate Store

Correct target column:

SalesLT.Customer.LastName

Create an Azure Monitor metric alert rule on database db1 using the metric:

CPU percentage

Configure the condition as:

Aggregation: Average

Operator: Greater than

Threshold: 50

Aggregation granularity / Period: 1 minute

Frequency of evaluation: 1 minute

Evaluation period / Lookback window: 5 minutes

Action group email: admin@contoso.com

Azure SQL Database exposes CPU percentage as a platform metric, and Azure Monitor metric alerts can send notifications through action groups such as email. Microsoft describes SQL Database alerts as metric-based alerts that can send email when metrics such as CPU usage reach a defined threshold.

Azure Portal Method — Recommended for Simulation

Step 1: Open the db1 Azure SQL database

Sign in to the Azure portal.

Search for SQL databases.

Open the database named:

db1

Do not open the SQL logical server unless the alert needs to apply to all databases. This task is specifically for db1, so the alert scope must be the db1 database resource.

Step 2: Create a new alert rule

From the db1 database page:

In the left menu, select Alerts.

Select Create.

Select Alert rule.

Microsoft’s Azure Monitor workflow allows you to create an alert rule directly from the target resource. When you create it from a resource, the resource is automatically set as the alert scope.

Step 3: Confirm the alert scope

On the alert rule page, confirm the scope is the Azure SQL database:

db1

The resource type should be similar to:

SQL database

Microsoft.Sql/servers/databases

If the scope is the SQL server instead of the database, remove it and select the db1 database resource.

Step 4: Add the alert condition

Under Condition, select Add condition.

Choose the metric:

CPU percentage

Sometimes it appears as:

CPU percent

or metric name:

cpu_percent

For Azure SQL Database, CPU percentage represents CPU consumption toward the database workload limit, expressed as a percentage.

Step 5: Configure the signal logic

Configure the alert logic exactly like this:

Setting

Value

Threshold type

Static

Aggregation type

Average

Operator

Greater than

Threshold value

50

Unit

Percent

Aggregation granularity / Period

1 minute

Frequency of evaluation

1 minute

Evaluation period / Lookback window

5 minutes

This means Azure Monitor evaluates the CPU metric every minute, using one-minute metric samples, and fires the alert only when the average CPU percentage is greater than 50% across the five-minute evaluation window.

Be precise here. The task says:

average CPU percentage utilization is greater than 50 percent for five minutes sampled at one-minute intervals

So the correct choices are:

Average

Greater than 50

Every 1 minute

Over the last 5 minutes

Azure Monitor metric alert rules combine the monitored resource, the metric condition, and action groups that run when the condition is met.

Step 6: Create the email action group

Under Actions, select:

Create action group

Configure the basics:

Setting

Value

Subscription

Use the current subscription

Resource group

Use the lab resource group

Action group name

AG-db1-CPU-Email

Display name

db1CPU

Then go to Notifications.

Add a notification:

Setting

Value

Notification type

Email/SMS message/Push/Voice

Name

EmailAdmin

Email

admin@contoso.com

Select OK, then Review + create, then Create.

Action groups define the notification or automation action that runs when an alert fires. Microsoft documents email as a supported action group notification type.

Step 7: Configure alert rule details

Under Details, configure:

Setting

Value

Severity

2 or 3

Alert rule name

db1 CPU greater than 50 percent

Description

Alert when average CPU percentage for db1 is greater than 50 percent for 5 minutes.

Enable upon creation

Yes

Severity is usually not specified by the task, so any reasonable severity is acceptable. In an exam lab, I would use Severity 2 for CPU performance impact.

Step 8: Review and create

Select Review + create.

Confirm the condition says something equivalent to:

Whenever the average CPU percentage is greater than 50

Confirm the evaluation settings are:

Check every 1 minute

Lookback period 5 minutes

Confirm the action group sends email to:

admin@contoso.com

Select Create.

Verification

After creation:

Open db1.

Go to Alerts.

Select Alert rules.

Confirm the alert rule exists and is enabled.

Open the rule and verify:

Scope: db1

Signal: CPU percentage

Aggregation: Average

Operator: Greater than

Threshold: 50

Evaluation frequency: 1 minute

Window size: 5 minutes

Action group: admin@contoso.com

Azure CLI Method

Use this only if the simulation gives you Cloud Shell.

First get the database resource ID:

az sql db show \

--resource-group < resource-group-name > \

--server < sql-server-name > \

--name db1 \

--query id \

--output tsv

Create the action group:

az monitor action-group create \

--resource-group < resource-group-name > \

--name AG-db1-CPU-Email \

--short-name db1CPU \

--action email EmailAdmin admin@contoso.com

Create the metric alert:

az monitor metrics alert create \

--name " db1 CPU greater than 50 percent " \

--resource-group < resource-group-name > \

--scopes < db1-resource-id > \

--condition " avg cpu_percent > 50 " \

--window-size 5m \

--evaluation-frequency 1m \

--action AG-db1-CPU-Email \

--description " Alert when average CPU percentage for db1 is greater than 50 percent for 5 minutes. "

The metric name commonly used for Azure SQL Database CPU percentage in CLI/ARM contexts is:

cpu_percent

SSMS Clarification

SSMS is not the correct tool for this task.

Do not configure Database Mail. Azure SQL Database does not use SQL Server Agent/Database Mail in the same way as SQL Server on a VM or SQL Managed Instance. This requirement is an Azure Monitor metric alert requirement.

Correct tool:

Azure portal > db1 > Alerts > Create alert rule

Wrong tool:

SSMS Database Mail

Final Exam-Lab Configuration

Use this exact configuration:

Resource: db1

Alert type: Metric alert

Metric: CPU percentage

Aggregation: Average

Operator: Greater than

Threshold: 50

Aggregation granularity: 1 minute

Evaluation frequency: 1 minute

Evaluation period/window: 5 minutes

Action group notification: Email

Email recipient: admin@contoso.com

That completes the task.
