Free Enterprise Routing and Switching - Professional (JNCIP-ENT) Practice Questions

OSPFv2 (IPv4) and OSPFv3 (IPv6) share many fundamental concepts, such as the SPF algorithm and the use of areas, but they have distinct differences in how they handle prefix information and LSA headers in Junos OS.

Backbone Requirement (Option C): Both OSPFv2 and OSPFv3 utilize a hierarchical structure. In both versions, all areas must connect to a central Area 0 (the backbone) to allow for inter-area routing. If an area is not physically connected to Area 0, a virtual link must be established.

Flooding Scope (Option D): One of the significant architectural changes in OSPFv3 is the inclusion of the flooding scope directly into the LSA header. In OSPFv3, the LS Type field is expanded to 16 bits, where the top three bits define the flooding scope (e.g., Link-local, Area, or AS scope). This allows routers to understand how far an LSA should be propagated without needing to understand the specific LSA type itself.

LSA Prefix Information (Option A): This statement is misleading. In OSPFv2, Router and Network LSAs (Type 1 and 2) carry both topology and prefix information. However, a key design goal of OSPFv3 was to separate topology from prefix information. In OSPFv3, Type 1 and 2 LSAs only describe the topology, while prefixes are carried in new LSA types: Intra-Area-Prefix-LSAs (Type 9) and Link-LSAs (Type 8).

Processing (Option B): OSPFv2 is processed " per-subnet " because it forms adjacencies based on IPv4 subnets. OSPFv3 is processed " per-link " , meaning it forms adjacencies between interfaces on the same physical link regardless of whether they share a common IPv6 prefix.

In an EVPN-VXLAN architecture, the interaction between the control plane (EVPN) and the data plane (VXLAN) is defined by specific functional components:

VTEP (VXLAN Tunnel End Point): These are the entities responsible for the encapsulation and de-encapsulation of Layer 2 Ethernet frames into Layer 3 UDP/IP packets. A VTEP can be a physical switch (like a QFX or EX series) or a software-based entity. When traffic enters the fabric, the ingress VTEP wraps it in a VXLAN header; the egress VTEP removes this header before delivering it to the destination host. (Option B)

VNI (Virtual Network Identifier): The VNI is a 24-bit field in the VXLAN header that allows for up to 16 million unique identifiers. It is used to identify specific broadcast domains (or VLANs) within the overlay network. Each VNI effectively represents a virtualized Layer 2 segment that is stretched across the Layer 3 underlay. (Option D)

Incorrect statements: Option A is incorrect because VNIs are identifiers, not the " engine " that performs encapsulation—that is the VTEP ' s job. Option C is incorrect because VTEPs identify the endpoints of a tunnel, not the individual broadcast domains themselves.

The exhibit illustrates an Autonomous System (AS 65512) receiving the same prefix ($203.0.113.0/24$) from two different neighbors, ISP A and ISP

B.

A.

B.

In Junos OS, the figure-of-merit is an internal numerical value used by the BGP Route Damping mechanism to quantify the stability of a specific BGP route. When a route " flaps " (becomes unstable), the Junos OS increases this value by assigning a specific penalty based on the type of event that occurred:

The route is withdrawn (Option A): When a BGP neighbor sends a withdrawal message for a prefix, Junos assigns a significant penalty—typically 1,000 by default—to the route ' s figure-of-merit.

The route is readvertised (Option C): When a previously withdrawn route is announced again by the neighbor, the Junos OS adds another penalty to the figure-of-merit value to track the continued instability.

The route ' s path attributes changed (Option E): If a route remains reachable but its BGP attributes (such as the AS Path or Community) change, it is considered a flap. Junos assigns a smaller penalty—typically 500 by default—for this attribute change.

As the figure-of-merit accumulates and exceeds a predefined suppress threshold , the route is suppressed and no longer used for forwarding. Over time, the value decreases according to a configured half-life until it falls below a reuse threshold , at which point the route becomes active again. Factors like local preference or the origin (IBGP/EBGP) do not trigger these internal penalty increments for the figure-of-merit.

Junos OS 24.4 handles multicast traffic using two distinct models based on whether the source is known in advance.

Knowledge and Sources (Option A): PIM-ASM (Any Source Multicast) is designed for " many-to-many " communication where receivers join a group ($*,G$) and rely on a Rendezvous Point (RP) to discover active sources. In contrast, PIM-SSM (Source-Specific Multicast) is for " one-to-many " scenarios where receivers must already know the exact source IP ($S,G$) before joining.

Protocol and RP Logic (Option D): PIM-SSM bypasses the RP entirely. It relies on IGMPv3 messages from the host, which explicitly include both the source address and the group address. This allows the last-hop router to build a Shortest Path Tree (SPT) directly toward the source immediately.

Register Process (Option B): While PIM-ASM does use registers, it is the First-Hop Router (Designated Router on the source segment) that sends the register to the RP, not the receiver ' s DR.

RP Role (Option C): This is exactly backwards; PIM-ASM requires an RP for source discovery, whereas PIM-SSM does not use one at all.
