NSE5_SSE_AD-7.6 Practice Questions

"If a flow is identified as belonging to a defined application category (such as social media), FortiGate will match it to the corresponding service rule (rule 2) and route it through the specified interface, such as port2. However, if the application is not recognized during the session setup, the system defaults to load balancing the traffic using the available tunnels according to the policy for unclassified traffic, ensuring continuous connectivity while waiting for application classification."

This guarantees both performance and resilience.

According to theSD-WAN 7.6 Core Administratorcurriculum and the diagnostic outputs shown in the exhibit, the reason traffic is steered toHUB1-VPN3instead of the expectedHUB1-VPN1(defined in SD-WAN rule ID 1) can be explained by two core routing principles in FortiOS:

Valid Route Requirement (Option A): In thediagnose sys sdwan service 4output (which corresponds to Rule ID 1), it shows the rule has membersHUB1-VPN1,HUB1-VPN2, andHUB1-VPN3. A key principle of SD-WAN steering is that for a member to be "selectable" by a rule, itmust have a valid route to the destinationin the routing table (RIB/FIB). If the routing table output (the third section of the exhibit) shows a route to 10.0.0.0/8 viaHUB1-VPN3butnotthroughHUB1-VPN1, the SD-WAN engine will skip HUB1-VPN1 entirely because it is considered a "non-reachable" path for that specific destination.

Policy Route Precedence (Option D): In the FortiOS route lookup hierarchy,Regular Policy Routes (PBR)are evaluatedbeforeSD-WAN rules. If an administrator has configured a traditional Policy Route (found underNetwork > Policy Routes) that matches traffic destined for 10.0.0.0/8 and specifiesHUB1-VPN3as the outgoing interface, the FortiGate will forward the packet based on that policy route and willnever evaluate the SD-WAN rulesfor that session. This "bypass" occurs regardless of whether the SD-WAN rule would have chosen a "better" link.

Why other options are incorrect:

Option B: While member configuration priority (cfg_order) is a tie-breaker in some strategies, the SD-WAN rule logic is only applied if the routing table allows it or if a higher-priority policy route doesn't intercept the traffic first.

Option C: Lower route priority (which means higher preference in the RIB) affects theImplicit Rule(standard routing). However, SD-WAN rules are designed tooverrideRIB priority for matching traffic. If HUB1-VPN1 was a valid candidate and no Policy Route existed, the SD-WAN rule would typically ignore RIB priority to enforce its own steering strategy.

According to theFortiSASE 7.6 Feature Administration Guide, steering bypass destinations (also known as split tunneling) allow administrators to optimize bandwidth by redirecting specific trusted traffic away from the SASE tunnel to the endpoint's local physical interface.

Destination Types (Option C): When creating a bypass destination, administrators can select from four distinct types:Infrastructure(pre-defined apps like Zoom/O365),FQDN(specific domains),Local Application(identifying processes on the laptop), orSubnet(specific IP ranges).

Apply Condition (Option B): The "Apply" condition is a flexible setting that allows the administrator to choose when the bypass is active. It can be applied to endpoints that areOn-net(inside the office),Off-net(remote), orBoth. This ensures that if a user is in the office, they don't use the SASE tunnel for local resources, but if they are home, they might still bypass high-bandwidth sites like YouTube to preserve tunnel capacity.

Why other options are incorrect:

Option A: Subnet is one of four types and is not the only type supporting these conditions.

Option D: The system explicitly supports "Both" to ensure consistency across network transitions.
