Free Implementing Cisco Enterprise Network Core Technologies (350-401 ENCOR) v1.2 Practice Questions

Solution:

R30

Config t

router ospf 10

router-id 10.0.1.30

int ran lo0 , e0/0-1

ip ospf 10 a 0

exit

int et0/2

ip ospf 10 a 50

exit

router ospf 10

area 50 range 10.10.0.0 255.255.128.0

area 50 range 10.50.0.0 255.255.128.0

end

A → 3

B → 1

C → 2

D → 4

YANG models describe configuration and operational state data in a structured tree. A leaf represents a single simple value, such as a string, integer, boolean, or enumeration, so it maps to “contains simple data like an integer or a string.” A leaf-list represents a sequence of leaf values of the same type, so it maps to the array-style definition. A container is an interior node in the YANG schema tree. It does not itself hold a scalar value; instead, it contains child nodes and organizes related data. A list represents a set of repeated entries and is used to group related child nodes into list entries, commonly identified by a key. The important distinction is that a leaf has no child nodes, while containers and lists organize structured data below them. In ENCOR automation, YANG is critical because protocols such as NETCONF and RESTCONF use YANG models to define valid configuration and operational data paths. References/topics: ENCOR Automation, YANG data models, NETCONF, RESTCONF, leaf, leaf-list, container, list, model-driven programmability.

access-list-sec-rule, deny, ip, dst-any
