300-610 Practice Exam Questions and Answers

A network consultant must design a high availability interconnection of a clustered Cisco UCS Fabric Interconnect toward two upstream Layer 2 switches. The Ethernet interconnection must use all redundant links and have no impact on the STP domain size.

Which connectivity solution must be used?

A customer needs to deploy a three-tier network architecture that will consist of web, and other business-critical applications. The solution will include Cisco UCS 6324 Fabric interconnects managing B and C Series servers The Fabric interconnects will be connected to the cisco nexus 7706 series switch for network access. A storage array will be directly connected to the UCS deployment. Which type must be used to meet these requirements?

The network infrastructure team is beginning to automate routine tasks within the Cisco ACI fabric and is searching for the appropriate solution The solution must not require any additional software installed on the Cisco APIC Networking team members lack automation experience and prefer to use a tool that does not require in-depth programming knowledge Finally configuration within the Cisco ACI fabric is rarely modified or removed Which solution must the team choose?

An engineer must integrate Layer 4 to Layer 7 services within Cisco ACI Fabric. The main requirement is to have a single point of configuration for network elements and firewall policies.

Which action meets these requirements?

The user traffic destined to all web servers located in the data center must pass first through a set of firewalls for deep packet inspection. A network architect must design the Cisco Intelligent Traffic Director (ITD) deployment that meets these requirements:

• The firewalls are connected to a set of two Cisco Nexus switches to provide stateful handling of traffic.
• The ITD service is provided for inside and outside segments of the firewall.

Which ITD deployment mode must be implemented to meet these requirements?

A network engineer must design a Cisco HyperFlex solution based on these requirements:

• two clusters in the main data center consisting of five HyperFlex nodes

• one edge node tor the remote branch

• cluster nodes that use one rack unit of space

Which two devices should be used in the remote branch cluster for this design? (Choose two.)

After experiencing traffic disruptions from the failure of a single router, a customer asks an engineer to design a solution that will prevent this from occurring in the future. While examining the customer’s environment, the engineer discovers that the routers are manufactured by a variety of different vendors, and they have varying amounts of CPU and memory resources. Additionally, several of the customer’s applications require the ability to fine-tune the load-balancing parameters between multiple routers. Which solution should be used to meet these requirements?

A Cisco engineer is developing a custom application that can run natively in Cisco NX-OS on Nexus 9000 and Nexus 3000 platforms For the NX-SDK application to run the engineer enables the NX-SDK feature on the device Then the NX-SDK is imported into the application via an import nx_sdk_py statement. The engineer creates custom CLI commands and defines custom CLI command syntax within the sdkThread function When CLI commands originate from an NX-SDK application what class is this?

Refer to the exhibit Due to power limitations at the customer data center, the engineering team must decommission one of the modular switches In the new design the customer must ensure that the OSPF process is fully protected on the remaining switch and minimize OSPF flapping in case of any module failure. Which solution fulfills the requirements for the new design?

An engineer working for a private telecommunication company with an employee id 4298 53 420 must evaluate connectivity to the new data centre location based on Cisco Nexus 7000 Series Switches. The IP connectivity is already supplied by the service provider. The solution must provide a Layer 2 extension and optimize the traffic localization Which technology supports these requirements?

An engineer must implement an iSCSI storage connectivity in the existing Cisco UCS environment. The environment is based on Cisco UCS С-Series rack server, Cisco Nexus 1000V Series Switches, and VMware ESXi hosts. The implementation must meet these requirements:

• Provide multipathing and high availability in the event of a critical path failure.
• Be cost-effective and not require the purchase of new equipment.

Which two components must be selected to meet these requirements? (Choose two.)

The management of the Cisco Nexus switches is provided over an isolated put-of-band network. The VDC feature is configured on the Cisco Nexus core switches. How is out-of-band management access provided for each VDC?

What is the disadvantage of asynchronous storage replication as compared to synchronous storage replication in a disaster recovery design?

A customer deploys 32 virtualization hosts in a Cisco UCS domain. All hosts run in the same cluster and have Identical hardware specifications. The operating system requires that all firmware is consistent across the hosts (or driver support. The customer must provision additional interfaces later for expandability. Which feature of Cisco UCS Manager meets these requirements?

An engineer is installing a Cisco Nexus 7000 Series Switch with F2-Series I/O Module. The company's strict security policy requires that the port be in-band. The engineer must also keep these

considerations in mind:

• The customer's security requirements mandate the use of a secure management mechanism that supports authentication and encryption.
• The port should support management over IP.

Which port type must be used to meet these requirements?

Which orchestration tool provides a graphical interface to manage LAN and SAN fabrics?

Which pools are used when a vNIC template is created in Cisco UCS Manager?

A company runs mission -critical infrastructure in a single data center. Due to business growth It plans to open more data center in the coming years. A network engineer is asked to recommend a network technology for data center interconnection that allows scalability and seamless VM mobility while providing maximum security and fault isolation between data center. Which technology must be used to meet these requirements?

An engineer Installs a B-Series server in a Cisco UCS chassis that contains a pair of UCS-IOM-2208XP I/O modules. The full bandwidth of the I/O module must be utilized. Which two elements should be used in this environment? (Choose two.)

A Cisco engineer is preparing a service profile template for a design, which consists of 20 x UCS B200M6 blade servers 2 x UCS 6454 Fabric Interconnect in End Host Mode, and 3 x UCS 5108 server chassis with 2408 Fabric Extenders The blade servers are equipped with VIC 1480 adapters The engineer does not configure a vNIC/vHBA placement policy in the service profile and the vNICs and vHBAs are assigned to the vCon in a particular order What is the mapping scheme in which Cisco UCS assigns the vCons based on the type of server and the selected virtual slot?

An engineer must use OTV for layer 2 connectivity between data centers to support virtual machine between the customer sites. To support this requirement, the engineer must ensure the existence of the same default gateway on both sites. Additionally, the operations team report high bandwidth utilization on site A and wants to optimize the outbound traffic flows to use a DC exit point. Which feature must be used to meet these requirement?

What is a design consideration when implementing FSPF?

Refer to the exhibit.

The Cisco Nexus Series Switch with hostname Nexus! is the default gateway for server A and server B Both servers must have reachability to the internet; however, server A internet traffic must pass through the firewall for deep packet inspection. Also, the firewall must inspect any communication between server A and server

B.

Drag the requirements from the left onto the correct policy types on the right.

Which Ethernet to Cisco Fabric Interconnect connectivity configuration is supported when FCoE is implemented?

A cloud service provider is managing day-2 operations of over 200 blade servers installed in the Cisco UCS environment. This pool of network resources is providing virtual networks to their customers. To successfully operate this environment, frequent changes to vNICs and other operational policies are required across multiple UCS domains. The operations team must streamline these repetitive tasks. Which orchestration tool must be used to meet this requirement?

An engineer must design a Cisco HyperFlex solution to support a virtualized environment in a single data center location. The design must consider these customer requirements:

• a large-scale cluster with eight or more nodes
• distributed high-performance file system for virtualized servers
• high fault tolerance to multiple node failures

Which action meets these objectives?

An engineer must connect an existing Cisco Fabric Interconnect to an IP-based storage array. The connection be a channel made directly between the fabric interconnect expansion module and the storage array. The engineer must also consider that the environment is running FCoE for storage and uses QoS to prioritize traffic. Which port type should be used to meet these requirements?

Which element is the main functional component of the architecture that separates the internal fabric and the external network that connects sites when VXLAN EVPN is deployed multisite?

An engineer seeks a solution to retrieve routing information from Cisco Nexus switches. The data must be exported to a web application in a JSON or XML data format for monitoring and must be encrypted during transmission. The solution must not require extensive knowledge to support and should be simple to implement.

Which technology accomplishes these goals?
