Free Implementing and Operating Cisco Security Core Technologies (SCOR 350-701 v2.0) Practice Questions

Wired 802.1X authentication is a port-based network access control that uses the physical characteristics of the switched LAN infrastructure to authenticate devices attached to a LAN port1. Wired 802.1X authentication requires three components: a supplicant, an authenticator, and an authentication server2. The supplicant is the client device that requests access to the network. The authenticator is the switch port that controls the access to the network based on the authentication result. The authentication server is the server that validates the credentials of the supplicant and sends the authentication result to the authenticator3.

In this question, option A is correct because Cisco Identity Service Engine (ISE) is an example of an authentication server that supports wired 802.1X authentication4. Option C is correct because Cisco Catalyst switch is an example of an authenticator that supports wired 802.1X authentication5. Option B is incorrect because Cisco AnyConnect ISE Posture module is not a supplicant, but a software component that checks the compliance status of the supplicant. Option D is incorrect because Cisco ISE is not an authenticator, but an authentication server. Option E is incorrect because Cisco Prime Infrastructure is not an authentication server, but a network management tool.

 1: Wired 802.1X Deployment Guide - Cisco 2: 802.1X Authenticated Wired Access Overview | Microsoft Learn 3: About 802.1X Authentication - Aruba 4: Cisco Identity Services Engine - Products & Services - Cisco 5: Cisco Catalyst 2960-X Series Switches - Products & Services - Cisco : Cisco AnyConnect Secure Mobility Client Administrator Guide, Release 4.9 - Configure Posture [Cisco AnyConnect Secure Mobility Client] - Cisco : Cisco Prime Infrastructure - Products & Services - Cisco

 PAC files are scripts that tell web browsers how to use proxies on the network. They use if-else statements to determine whether to use a proxy or a direct connection for traffic between the PC and the host, based on criteria such as the destination URL, the source IP address, or the network subnet12. The WSA can host PAC files on port 9001 by default, and this port can be changed in the PAC file hosting settings2. If the WSA host port is changed, the default port does not redirect web traffic to the correct port automatically; the browser needs to point to the new port in the PAC file URL2. The WSA does not host PAC files on port 6001 by default2. PAC files do not direct traffic through a proxy when the PC and the host are on the same subnet by default; this behavior depends on the PAC file logic12. References:

PAC file format

PAC file hosting on WSA

 To add switches into the fabric, administrators can use PowerOn Auto Provisioning (POAP) or Seed IP methods. POAP is a feature that automates the process of upgrading software images and installing configuration files on Cisco switches that are being deployed in the network for the first time. Seed IP is a method that allows administrators to specify the IP address of a switch that is already part of the fabric, and then use it to discover and add other switches that are connected to it. Both methods enable administrators to control how switches are added into DCNM for private cloud management. References:

POAP, section “PowerOn Auto Provisioning (POAP)”.

Seed IP, section “Add Switches”.

https://www.cisco.com/c/en/us/td/docs/security/ise/1-4-1/admin_guide/b_ise_admin_guide_141/b_ise_admin_guide_141_chapter_01110.html
